Applications
● Temperature control and examination of household electrical appliance(such as air-condition, microwave oven, induction cooker, toaster fanner, electric heating and so on)
● Temperature examination and compensation of the automatic work facilities(such as copycat, printer and so on)
● Battery of mobile telephone, battery pile
● Temperature compensation of loops of instrument, integrate circuit, quartz crystal monofier and thermocouple.
Characteristics
● Good stability and security
● Broad range of resistance
● Capability of operating in the bad envi ronment of high temperature and high humidity because of glassencapsulation framework.
● Small size, light weight, strong frame, easy automatic installation (on the printed-circuit board)
● Fast response to the temperature,high delicacy.
Main techno-parameter
● The range of resisitance under the rated zero power(R25): 0.1-3780KΩ
● The allowable tolerance of R25: ±1%，±2%，±3%，±5%，±10%
● The range of B value: 3100～4500K
● The allowable tolerance of (label by requirment)B value: ±0.5%，±1%
● Dissipation factor: ≥2mW/℃(in still air)
● Thermal time constant: ≤20S(in still air)
● The range of operating temperature: -55℃～+250℃ Rated power: ≤50mW
※ Disclaimer
Users should verify actual device performance in their specific applications
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
