Uses of Fast Recovery Diodes in Solar Inverters? Usage Precautions?

Fast Recovery Diodes (FRDs) play a primary role in solar inverters by enabling reverse current conduction and discharging the charge during the turn-off process of IGBTs.

The following precautions should be observed when using FRDs:
1. During inverter design, select the appropriate FRDs, ensuring their rated current, voltage, and other parameters meet the inverter's operational requirements.
2. Ensure proper heat dissipation conditions for the FRDs. In high-temperature environments, implement reasonable cooling measures to prevent failure due to overheating.
3. The positive and negative terminals of the FRDs must be connected correctly to ensure normal operation.
4. Avoid operating the FRDs beyond their rated current or voltage, as this may affect their lifespan and lead to failure.
5. Regularly inspect and test the working condition of the FRDs, performing timely maintenance and replacement to ensure the inverter's proper operation.

In summary, in solar inverters, FRDs serve functions such as protecting power switching devices, conducting reverse current, and discharging charge during IGBT turn-off. Proper use and maintenance of FRDs are crucial factors in ensuring the continuous and stable operation of the inverter.
