Note: Test equipment 1.2/50 8/20us combined wave generator surge test voltage range is 0.1KV-6KV, the tested equipment power supply voltage DC 0-60V, AC220V, maximum working current 10A.

Note: Signal line surge test, test equipment is 1.2/50 8/20us combined wave generator, 10/700 5/320us (0.2-6KV) combined wave generator

If using coupling decoupling network, the coupling device uses gas discharge tube, so test voltages above 0.5KV will have output, can test 1, 2, 4, 8 data lines.

Note: Our company's electrostatic generator voltage range is 0.2KV-30KV, the commonly used module is 150pF, 330 ohms

If testing automotive products, please note, energy storage capacitor: □150pf, □330pf, Discharge resistor: □330 ohms, □2000 ohms

Note: Burst generator voltage range 0.2-5KV, the tested equipment power supply voltage DC 0-60V, AC220V, maximum working current 10A.

Note: Burst generator voltage range 0.2-5KV, the tested equipment power supply voltage DC 0-60V, AC220V, maximum working current 10A.

□Waveform 1   Severity level: □Ⅰ/Ⅱ -75V, □Ⅲ -112V, □Ⅳ -150V, □Other _____V   Repetition time: □0.5s, □Other _____s

□Waveform 2a Severity level: □Ⅰ/Ⅱ +37V, □Ⅲ +55V, □Ⅳ +112V, □Other _____V Repetition time: □0.2s, □Other _____s

□Waveform 2b Severity level: □Ⅰ/Ⅱ +10V, □Ⅲ +10V, □Ⅳ +10V, □Other _____V Repetition time: □0.5s, □Other _____s

□Waveform 3a Severity level: □Ⅰ/Ⅱ -112V, □Ⅲ -165V, □Ⅳ -220V, □Other _____V Repetition time: □90ms, □Other _____ms

□Waveform 3b Severity level: □Ⅰ/Ⅱ +75V, □Ⅲ +112V, □Ⅳ +150V, □Other _____V Repetition time: □90ms, □Other _____ms

□Waveform 1   Severity level: □Ⅰ/Ⅱ -300V, □Ⅲ -450V, □Ⅳ -600V, □Other _____V Repetition time: □0.5s, □Other _____s

□Waveform 2a Severity level: □Ⅰ/Ⅱ +37V, □Ⅲ +55V, □Ⅳ +112V, □Other _____V Repetition time: □0.2s, □Other _____s

□Waveform 2b Severity level: □Ⅰ/Ⅱ +20V, □Ⅲ +20V, □Ⅳ +20V, □Other _____V Repetition time: □0.5s, □Other _____s

□Waveform 3a Severity level: □Ⅰ/Ⅱ -150V, □Ⅲ -220V, □Ⅳ -300V, □Other _____V Repetition time: □90ms, □Other _____ms

□Waveform 3b Severity level: □Ⅰ/Ⅱ +150V, □Ⅲ +220V, □Ⅳ +300V, □Other _____V Repetition time: □90ms, □Other _____ms

□5a Parameters UA_____V, US_____V, Ri_____Ω, td_____ms

□5b Parameters UA_____V, US_____V, US#_____V, Ri_____Ω, td_____ms
